OVERVIEW
The AgileX Scout Mini is an all-terrain high-speed UGV with four-wheel differential drive, independent suspension, in-situ differential rotation and other features. This small robot is a versatile platform designed for various industrial tasks. It is equipped with advanced technologies and features that enable it to navigate different environments and gather essential information.
FEATURES
Quick Deployment: The Scout Mini robot can be quickly deployed in various situations, allowing for rapid response and assessment. Its compact size and lightweight design facilitate swift transportation and setup, enabling efficient operations and reducing response times.
Maneuverable and Versatile: The compact size of the Scout Mini robot enables it to navigate through tight spaces and challenging terrains. It can access areas that may be difficult for larger robots or humans to reach, making it highly maneuverable and versatile.
Stealthy Operations: The small robot size allows it to operate discreetly and quietly, making it suitable for stealthy surveillance operations. It can go unnoticed in sensitive areas, providing valuable intelligence without alerting potential threats.
TECHNICAL SPECIFICATIONS
| Dimensions | 612L x 245W x 580H mm |
| IEC Ingress Rating | IP22 |
| Weight | 23kg |
| Payload Capacity | 10kg (Standard Wheel) 20kg (Mecanum Wheel) |
| Top Speed | 10k/h (Standard Wheel) 2.8km/h (Mecanum Wheel) |
| Runtime | Up to 8h |
| Charging Time | 2h |
| Operational Temperature Range | -10°C-45°C |
| Max Climbing Grade | 30° (full payload) |
| Obstacle Clearance | 70mm (Standard Wheel) |
| Ground Clearance | 115mm |
| Drive Motor | Hall Encoder |
| Battery | 24V 15Ah Lithium |
| Communication Interface | CAN Bus |
| Steering | Differential |
